AI Server
Edge Pro-1U
AI Server
Edge Pro-1U
Features
  • 1U Intel AC-IN Edge Pro server.
  • Single-socket Intel® Xeon® 6 platform.
  • Dual PCIe Gen5 slot design.
  • Flexible high-density storage options.
  • Comprehensive management and security features.
Single-socket Intel® Xeon® 6 architecture.
  • Supports Socket-E2 with a maximum TDP of 270W.
  • Supports DDR5-6400 memory and PCIe Gen5 expansion, enabling efficient edge computing with balanced power consumption.
Dual PCIe Gen5 slot design.
  • Equipped with two PCIe Gen5 x16 slots.
  • Supports single-slot HHHL or FHHL GPUs, network cards, or accelerators (e.g., NVIDIA L4).
High-density storage architecture with flexible expansion.
Supports up to 4 M.2 Gen5 and 6 E1.S Gen5 SSDs, with optional hardware/software RAID 0 / 1 / 5, providing a maximum total storage capacity of 46TB.
Intelligent management with multi-layer security protection.
Supports Redfish API, IPMI 2.0, HTML5 KVM, TPM 2.0, and secure boot to enable secure and centralized edge node management.
Edge Pro-1U Specification Table
EdgePro-1U_表格_EN
